• Max. Operating Pressure: 1.0 MPaG
• Max. Operating Temperature: 185℃
• Integral Motorized Bypass Valve
• Discharge Capacity: 50 - 420 kg/h
Space-saving Design
The trap has an integral bypass valve, eliminating the need for a separate bypass line and thereby saving space at the trap installation.
Reduced Pipeline Costs
Installation costs are reduced, as neither a bypass valve nor bypass piping are required.
Energy Conservation
Free float construction. The combination of the valve opening being under a continuous water-seal and the 3-point float seating prevents steam leakage.
Long Service Life
The high precision spherical float rotates, allowing its entire surface to function as valve sealing surfaces and thus ensuring long service life.
Inline Trap Maintenance
Maintenance is possible without removing the trap from the piping. For disassembly and cleaning, simply remove the four bolts securing the cover of the trap.
Application Areas
Steam main lines, steam headers, presses, tracers, etc.
