ỐNG MỀM COMPOSITE US HOSE, Type SGP951 and SSP951
Chemiflex® Heavy Duty Polypropylene Chemical Hose
Type SGP951 and SSP951
Construction:
Color/Cover: Gray blue stripe/PVC coated Nylon, Abrasion, Ozone resistant Gray blue stripe/PVC coated Nylon, Abrasion, Ozone resistant
Inner Wire: 316SS Stainless Steel Wire
Inner lining: High Density Polypropylene
Carcass: Polypropylene fabrics, films
Outer Wire: SGP951 Galvanized Steel / SSP951 316SS Stainless Steel
Extra: Special Color Coding and branding
Physical properties:
Temperature Range: -22°F to +212°F (-30°C to +100°C)
Maximum elongation: £10 on test pressure
Vacuum range: 26 inHg (660 mmHg), 0.9 bar
Electrical properties: Electrically Conductive / £2.5 ohm/m for sizes less than 2” / £1.0 ohm/m for size 2” and above
Standards: BS5842, NAHAD-600:2005
End Fittings: Specially designed end fittings have been developed for use with United Flexible composite hoses that have a unique leak-proof sealing face and specially machined helical spiral shank which engages into the corresponding internal helix wire when secured into the hose by either crimping or swaging the external ferrules. See page 22 for more information about end connections.
TECHNICAL DATA: TYPE SGP951 AND SSP951 |
|||||||||
Inside Diameter |
Working Pressure |
Min. Bend Radius |
Approx Weight |
Maximum Length |
|||||
Inches |
mm |
PSI |
Bar |
Inches |
mm |
lb/ft |
kg/m |
Feet |
Meters |
1 |
25 |
250 |
17 |
4 |
100 |
0.6 |
0.9 |
100 |
30 |
11/4 |
32 |
250 |
17 |
5 |
125 |
0.75 |
1.1 |
100 |
30 |
11/2 |
40 |
250 |
17 |
5 |
125 |
1 |
1.5 |
100 |
30 |
2 |
50 |
250 |
17 |
6 |
150 |
1.5 |
2.2 |
100 |
30 |
21/2 |
65 |
250 |
17 |
7 |
175 |
2.1 |
3.1 |
100 |
30 |
3 |
80 |
250 |
17 |
8 |
200 |
2.3 |
3.2 |
100 |
30 |
4 |
100 |
200 |
14 |
13 |
325 |
3 |
4.5 |
100 |
30 |
Pressure based on safety factor 4:1
Dimensions and weight are approximate and are subject to change
For additional technical data such as pressure drop, max. flow rates and tensile strength, please consult United Flexible engineering Increased operating temperatures will reduce working pressure of the assemblies
Fitting pressure rating may limit working pressure of the assembly Rated working pressure is @ 70°F (21°C)
