Type PGP949 - ỐNG MỀM COMPOSITE HOSE - UNITEDFLEXIBLE - USA
- Danh mục: ỐNG COMPOSITE
- Nhãn hiệu: US HOSE-MỸ
- Giá:
- Model: Type PGP949
- Size:
- Số lượng:
- Mua ngay Thêm vào giỏ
ỐNG MỀM COMPOSITE HOSE LOẠI PGP949
HIỆU: UNITEDFLEXIBLE (US HOSE)
XUẤT XỨ: MỸ
Nếu quý anh/chị cần tư vấn và báo giá sản phẩm này xin vui lòng liên hệ nhanh với chúng tôi qua Hotline: 0766226161 - Tel: 02835352125 - Zalo: 0902720814 / 0907450506 / 0902601875 hoặc Email: info@pm-e.vn
Chemiflex® Polypropylene Chemical Hose
Type PGP949
Applications: In-plant, tank truck, rail car liquid chemical suction and discharge.
Construction:
- Color/Cover: Yellow with a blue stripe/PVC coated Nylon, Abrasion, UV and Ozone resistant
- Inner Wire: Black Polypropylene Coated Steel Wire
- Inner lining: High Density Polypropylene
- Carcass: Polypropylene fabrics, films
- Outer Wire: Galvanized Steel
- Additional Options: Special Color Coding and branding
Physical properties:
- Temperature Range: -22°F to +212°F (-30°C to +100°C)
- Maximum elongation: ≤10% on test pressure
- Vacuum range: 26 inHg (660 mmHg), 0.9 bar
- Electrical properties: Electrically Conductive / ≤2.5 ohm/m for sizes less than 2”/ ≤1.0 ohm/m for size 2” and above
Standards: EN13765:2010, Type 3, NAHAD-600:2005
End Fittings: Specially designed end fittings have been developed for use with United Flexible composite hoses that have a unique leak-proof sealing face and specially machined helical spiral shank which engages into the corresponding internal helix wire when secured into the hose by either crimping or swaging the external ferrules. See page 22 for more information about end connections.
|
TECHNICAL DATA: TYPE PGP949 |
|||||||||
|
Inside Diameter |
Working Pressure |
Min. Bend Radius |
Approx Weight |
Maximum Length |
|||||
|
Inches |
mm |
PSI |
Bar |
Inches |
mm |
lb/ft |
kg/m |
Feet |
Meters |
|
1 |
25 |
200 |
14 |
4 |
100 |
0.60 |
0.9 |
100 |
30 |
|
11/2 |
40 |
200 |
14 |
5 |
125 |
0.80 |
1.20 |
100 |
30 |
|
2 |
50 |
200 |
14 |
7 |
175 |
1.20 |
1.80 |
100 |
30 |
|
3 |
80 |
200 |
14 |
8 |
200 |
2.00 |
3.00 |
100 |
30 |
|
4 |
100 |
200 |
14 |
12 |
300 |
2.7 |
4.1 |
100 |
30 |
Pressure based on safety factor 4:1
Dimensions and weight are approximate and are subject to change
For additional technical data such as pressure drop, max. flow rates and tensile strength, please consult United Flexible engineering
Increased operating temperatures will reduce working pressure of the assemblies
Fitting pressure rating may limit working pressure of the assembly
Rated working pressure is @ 70°F (21°C)
