VAN AN TOÀN KUNKLE VALVE MODEL 541/542/548
Brass or stainless steel safety valves with a choice of Buna-N (NBR), Viton® (FKM) or stainless steel seats that meet ASME section VIII, ‘UV’, for air/gas and are National Board certified
Features:
Kunkle Models 541, 542, 548
ASME Section VIII, Brass, Air/Gas, 'UV', National Board Certified
Models 541, 542, 548
ASME Section VIII, Brass, Air/Gas, 'UV', National Board Certified
Model Descriptions
Model 541: 1/4-inch or 1/2-inch Male NPT inlet. Brass body and seat with BUNA-N ball seal.
Model 542: Same as Model 541 except Viton Ball seal.
Model 548: Same as Model 541 except SS ball seal.
Pressure and Temperature Limits
Model 541: 3 to 200 psig -40oF to 200oF
Model 542: 3 to 200 psig -10oF to 300oF
Model 548: 3 to 400 psig -60oF to 300oF
Applications
Small to medium size, single and multistage, air compressors, intercoolers,aftercoolers, instrument/control
air lines and systems
Air tanks/receivers and pressurized equipment.
Options
No Options Available
Features and Benefits
High capacity with small size.
Every valve is 100% tested/inspected for pressure setting and leakage
Factory sealed to prevent tampering or disassembly.
