MODEL: GLV-20F
Van Cầu thân GANG, kết nối mặt bích
Áp dụng rộng rãi cho các ứng dụng hơi nước, không khí, nước hoặc dầu.
Category | Globe Valve | |
Specifications | Application | Steam , Air , Cold and hot water , Oil , Other non dangerous fluids |
MPa | ||
Max. pressure | BSV-10F: 1.4MPa, SV-20F: 2.8MPa (*1) | |
Max. temperature | BSV-10F: 300 degree C, BSV-20F: 350 degree C (*1) | |
Connection | BSV-10F: JIS 10KFF, BSV-20F: JIS 20KRF | |
(*1) | The relation between using puressure and using temperature is according to JIS B2051 Pressure-temperature rating. | |
Material | Body | Ductile Cast Iron |
Bonnet | Ductile Cast Iron | |
Valve | Stainless steel | |
Valve seat | Stainless steel | |
Bellows | Stainless steel |
