Feature | Direct type / Ductile cast iron / Screwed | |
Type | Direct operated bellows type | |
Specifications | Application | Steam |
Reduced pressure | 0.02 - 1.0MPa | |
Connection | JIS Rc screwed | |
Min. differential pressure | 0.05MPa | |
Max. pressure reduction ratio | 10:1 | |
Max. temperature | 220 degree(C) | |
Material | Body | Ductile cast iron |
Valve | Stainless steel | |
Valve seat | Stainless steel | |
Bellows | Phosphor bronze |
