Feature | Piston type / For gas application / Flanged | |
Type | Pilot operated piston type | |
Specifications | Application | Air , Other non-dangerous fluids |
Inlet pressure | 0.1 - 1.0MPa | |
Reduced pressure | 0.05 - 0.9MPa | |
Connection | PN16 flanged | |
Adjustable reduced pressure | 90% or less of the inlet pressure(gauge pressure) | |
Min. Differential pressure | 0.05MPa | |
Max. Press. reduction ratio | 20:1 | |
Max. temperature | 80 degree(C) | |
Material | Body | Ductile cast iron |
Main valve & seat | NBR & Stainless steel | |
Pilot valve & seat | NBR & Stainless steel | |
Piston & Cylinder | Brass or bronze |
